Rifle, 5.56mm, M16

For other items known as M16, see: M16 Disambiguation

Overview[]

M16 Assault Rifle

General Information

Designers

Eugene Stoner

Period Designed

1959

Manufacturer

Colt

Period Produced

1963 - ?

Number Built

>300,000

Developed From

AR-15

Developed Into

M16A1

In Service

1963 - 2001

Characteristics

Cartridge

5.56x45mm

RoF, Cyclic

700rpm

Expected Muzzle Velocity

varies, 960m/s with M855A1 round

Action

Gas-operated, rotating bolt

Firemodes

Full, semi, safe

Feed System

Detachable box magazine

Ammunition Loading

5.56x45mm STANAG magazines:
• USGI M16 Mag.: 20-rnd
• USGI M16 Mag.: 30-rnd
• (More)

Effective Range

550m

Maximum Range

3,600m

Dimensions

Barrel Length

508mm

Components

Upper Receiver

Slickside

Lower Receiver

Slabside

Handguard

A1

Attachments

Bipod

Can fit Rifle Bipod, M3

Stock

Stock Type

Solid fixed

The M16 (Colt 602) is an American assault rifle developed in the late early 1960s from the AR-15.

Variants[]

Rifle, 5.56mm, XM16E1: First model adopted by the US Army, produced from 1963 to 1967.
Rifle, 5.56mm, M16 — Colt Model 602: Production model adopted by the US Air Force.
Rifle, 5.56mm, M16A1 — Colt Model 603: Designation of standardized production of the XM16E1, produced from 1967.
Rifle, 5.56mm, M16A1E1 — Colt Model 645: Interim designs for what would become the M16A2.
Rifle, 5.56mm, M16A2 — Colt Model 701: Production model from 1982. Burst-fire replaces full-auto.
Rifle, 5.56mm, M16A2E1: M16A2 with modified "flat-top" upper receiver. Also known as M16A2 Enhanced Rifle.
Rifle, 5.56mm, M16A2E3: Prototype designation for M16A3.
Rifle, 5.56mm, M16A2E4: Prototype designation for M16A4.
Rifle, 5.56mm, M16A3 — Colt Model 901: M16A2 but with full-auto replacing the burst-fire.
Rifle, 5.56mm, M16A4 — Colt Model 945: M16A2 updated to M4 standard, retaining burst-fire.

Derivatives

Carbine, 5.56mm, M4 — Colt Model 920: Carbine model.
Rifle, Special Purpose 5.56mm, MK 12 MOD 0: Model designed for SOF, PRI Gen III handguard.
Rifle, Special Purpose 5.56mm, MK 12 MOD 1: Model designed for SOF, KAC RAS handguard.

Export

Colt Model 727: Special-made M16A2 carbine model for the United Arab Emirates, known as the "Abu Dhabi Carbine".
