53-K

Overview[]

53-K

Image 1
Image 2
Image 3
Image 4
Image 5
Image 6
Image 7

Information

Type

Anti-Tank Gun

Place of Origin

Soviet Union

Designer

M.N. Loginov

Manufacturer(s)

ZiK
Votkinskiy Zavod

Produced

1937 - 6 June 1938 (ZiK)
1937 (?) - 1944 (Votkinskiy)

Number Built

37,354

In Service

1937 - 1945

Designations

GAU Designation (?)

52-P-243A

Development

Developed Into

M-42

Specifications

Shell / Cartridge

45x310mmR

RoF, Cyclic

15 - 20rpm

Muzzle Velocity

760m/s

Maximum Range

4.4km

Breech

Semi-automatic vertical sliding wedge

Recoil

Hydro-spring

Elevation

-8° to +25°

Traverse

60°

Expected Life Span

450 rounds on average without failures

Dimensions

Length

6.4m

Barrel Length

2.07m (L/46)

Weight

560kg (combat)
1,200kg (travel)

The 53-K (53-К) (GAU Index: 52-P-243A / 52-П-243А), otherwise known as the 45mm protivotankovaya pushka obr. 1937g. (45mm anti-tank gun model of 1937), is a Soviet 45mm anti-tank gun developed in the 1930s.

The 53-K when captured by the Germans was known as the 4,5cm PaK 184/1(r).

Ammunition[]

53-UB-241: Armour-piercing.
53-UB-241M: Armour-piercing.
53-UB-243: Armour-piercing.
53-UBZR-243: Armour-piercing incendiary tracer.
53-UBR-243: Armour-piercing tracer.
53-UBR-243P: Sub-caliber armour-piercing tracer.
53-UBR-243SP: Armour-piercing tracer.
53-UD-243: Smoke.
53-UO-243: Fragmentation.
52-UO-243A: Fragmentation.
53-UO-243M: Fragmentation.
53-USh-243: Shrapnel.
53-UShch-243: Blank (?)
